WORLD'S MOST POWERFUL AND RELIABLE MULTI-ROTOR IN HIS CLASS

NEO

Performance and Design taken right to the edge

The NEO is a light weight multipurpose Remotely Operated Aerial Vehicle.The carbon framework and its smart design gives the Pilot in Command the opportunity to use it for almost every mission. Due to the flexibility of mounting different battery capacity packs, it enables you to swop payloads(*) easily in a range from 1 kg. up to 8 kg.
The Neo platform is a strong & stiff design.Vibrations being cancelled out due to its shapes and construction. It’s 8 powerful and custom designed brushless motors increases the level of redundancy and makes the system incredibly resistant for stronger wind gusts.
The motors are positioned in a 5% offset for ultra smooth descending manoeuvres.
All critical electronics are integrated in the carbon centrepiece and sufficiently cooled. Operations in high ambient temperatures or rainy days are no boundaries for the NEO platform.
NEO supports any Gimbal or Camera on the market up to 8KG/17Pounds. –Ronin M,L – Movi M5,M10,M15 – DJI, All Zenmuses – Gremsy H3,H6,H14,H16. etc.
SPECIFICATIONS

General features

Dimensions : 1107x1107x557 mm (LxWxH)

Weight : 6,85 kg ( Frame+LD+Electronics)

Material : 93% Aerospace engineered Carbon Fiber 44.5K

Wind sustainability : 24 knots ( depending on p-load)

GPS guided : on command supported

Autonomy : ATO (take off)
ACH (come home)
AL (landing)

Max airspeed : 20 m/s (41 knots)

Max altitude : 9,000 feet

Max range : 9,000 feet L.O.S.

Max flight time : ± 30 minutes

Max T.O.W. : 19KG ( 55% / 60% T-input)

Power Source

Brand: : Gens Ace

Material: : Lithium Polymer

Number of cells : 6

Capacity Mah : 10.000/12.000/16.000/22.000   22,2Volts

Number of packs : 2 packs

Autopilot system

Brand DJI Innovations

System : Wookong M.
( most reliable APS of 013/014/015)

Dimensions : FC 54x39x14,9mm
IMU 41,3×30,5×26,3mm
GPS 62mm (diameter) x 14,3 mm
PMU 39,5 x 27,6×9,8 mm

Weight : 224 gram

Operating Voltage : 22.2V

Consumption : 0.3A @12.5V

Output : 400Hz PWM

Operating Temp : -15C / 60C

Hovering Accuracy : ± 0.5m vertical
± 2.0m horizontal

Max ang. velocity : 150 deg/s

Max tilt angle : 35∘

Max desc/asc. : ± 6 m/s

Build in functions:   .Three Modes Autopilot

.Enhanced Failsafe

.Low Voltage Protection

.Go Home & Auto Landing

Motors

Brand : Kontronik AceCore Custom

Number of motors : 8

Weight per motor : 285 grams

KV rating : Custom on Requirements

Max power : 1200W

Poles : 14

Max. magnet temp : 155 Celsius

Max. coil temp : 160 Celsius

Pilot & Operator Communication TX & RX

Brand Futaba

Type : T14SG

Frequency : 2,4gHz

Modulations : Fasstest

Weight : 1500 gr

Dimension : 200x250x110mm

Battery : 7.2V 1,500mah Li-Po

Propellor

Brand: : Xoar AceCore Custom

Material : Carbon

Type : 18 inch

Max rpm : 20,000

Max Load : 5000 gr

Motor Controller

Brand : HRK / Kontronik

Type: : V3 XL full Tel / XL 55

Max voltage : 26 Volt

Max Amps : 55A/60A on each motor

MOT : 100C (max. operating temp)

with intelligent cut off

Warranty

2 years
